特徴
改善点●出力レベルの増加●シェルビングEQの安定性向上●GAIN値の整合性向上●交換不要のLED ジュエルライト搭載●コンプレッサー回路をトゥルーバイパス可能●メーターの大型化とLEDライトによる視認性の向上
Spec
- Microphone Input Impedance: Selectable, 500Ω or 2kΩ
- Balanced Line Input Impedance: 20kΩ
- Hi-Z Input Impedance: Selectable, 2.2MΩ or 47kΩ
- Maximum Microphone Input Level: -8dBu (2K input Imp. & 15 dB Pad in)
- Maximum Output Level: +23dBu (120VAC line)
- Internal Output Impedance: 80Ω
- Recommended Minimum Load: 600Ω
- Frequency Response: 20 Hz to 20 kHz +/- 0.5dB
- Maximum Gain: 40 dB (Line), +77dB (Mic)
- Noise Floor: -72 dBu 20 - 20kHz (Line In, unity Gain)
- Compressor Ratio: 3:1, soft knee, program dependent
- Limiter Ratio : ∞: 1, soft knee, program dependent
- Attack Time: 10 ms, program dependent
- Release Time: Dual stage: 60 ms for 1st release, then 1 - 15 sec.
- Tube Complement: (3) 12AX7, (1) 12AT7, (1) EL84
- Power Requirements: 100V / 120V / 240V
- Power Consumption: 30 Watts
- Power Connector: Detachable IEC power cable
- Dimensions: 483W x 89H x 311Dmm (2Uサイズ)
- Weight: 5.4kg
