Spec
Inputs
- Type
- Analogue, electronically balanced female XLRs (Pin 2 hot)
- Impedance
- 10k ohm
- Maximum input level
- +22dBu
- Common mode rejection
- Typically, -80dB at 1kHz
Outputs
- Type
- Analogue, electronically balanced male XLRs (Pin 2 hot)
- Signal drive capability
- <600 ohm
- Output impedance
- <60 ohm
- Maximum output level
- +22dBu
EXT inputs
- Type
- Analogue, electronically balanced Jack sockets
- Impedance
- 20k ohm
- Maximum input level
- +22dBu
- Common mode rejection
- Typically -60dB at 1kHz
Performance
- Maximum signal level any input or output
- +22dBu
- Frequency response
- ±0.5dBu (input to output), 20Hz to 20kHz
- Dynamic range
- >116dB (22Hz to 22kHz unweighted)
- Noise at main output with unity gain
- -94dBu
- Distortion at 1kHz 0dBu with steady unity gain condition
- <0.05%
- Signal delay
- 0 seconds
Compressor
- Threshold scale
- -50dB to +25dB
- Ratio scale
- Minus infinity (-4):1 to 1:1
- Attack scale
- 0.1s to 20ms
- Release scale
- 50ms to 2s
- Presence scale
- Minimum (flat) to maximum (-3dB at 5kHz)
- Gain scale
- 0dB to 18dB
Terminations
- Audio
- 3-pin XLRs (male and female) and 1/4" TRS balanced Jack sockets
- Power
- 3-pin IEC
Power Requirements
- Voltage
- 100VAC to 240VAC ±10%
- Frequency
- 50Hz to 60Hz
- Consumption
- <25W
その他
- Dimensions
- 44.5 mmH(1U) x 483 mmW x 305 mmD
- 本体重量
- 4.6 kg
- 作動環境
- +5°C to +40°C
- 保存環境
- -20°C to +60°C
