Spec
TS107
| Dimensions (WxHxD) [mm] | 230 x 355 x 300 |
|---|---|
| Dimensions (WxHxD) [“] | 9.06 x 13.98 x 11.81 |
| Free-field frequency range (-3dB) | 36Hz – 300Hz |
| Woofer | 165mm/6.5″ |
| Maximum SPL @ 1m | 102dB |
| Number of amplifiers | 1 |
| Total short-term output power | 100W |
| Protection limiter | ○ |
| Settings | |
| System volume (Satellite & Sub) | -inf. – +6dB |
| Subwoofer volume | -inf. – +6dB |
| Level-fix dip switch | ○ |
| Filter-fix dip switch | ○ |
| Phase switch | 0°/180° |
| Switchable Satellite filter | flat/80Hz |
| Variable Subwoofer filter | 60Hz-140Hz + LFE |
| Remote control | Sys. & Sub. Vol. |
| Connectors | |
| XLR in left (impedance) | ○ (10k) |
| XLR in right (impedance) | ○ (10k) |
| XLR in LFE (impedance) | ○ (10k) |
| XLR out satellite left (impedance) | ○ (10k) |
| XLR out satellite right (impedance) | ○ (10k) |
| XLR out (Sub/LFE) (impedance) | ○ (10k) |
| Power consumption | |
| Standby | < 1W |
| Full output | 120VA |
| Misc. | |
| Weight kg/lb. | 8.2 / 18.1 |
SC205
| Dimensions (WxHxD) [mm] | 175 x 275 x 233 |
|---|---|
| Dimensions (WxHxD) [“] | 6.89 x 10.83 x 9.17 |
| Free-field frequency range (-3dB) | 53Hz – 21kHz |
| Tweeter | AMT RS1 |
| Mid-Woofer | 130mm/5″ |
| Cross-over frequency | 3000Hz |
| Maximum SPL @ 1m | 101dB |
| Number of amplifiers | 2 |
| Total short-term output power | 100W |
| Output power (woofer) | 50W |
| Output power (tweeter) | 50W |
| Protection limiter | ○ |
| Settings | |
| Volume | -inf. – +6dB |
| High-shelf filter (-5dB – +3dB) | > 3kHz |
| Desk filter boost (0dB – +3dB) | 80Hz |
| Desk filter cut (-5dB – 0dB) | 180Hz |
| Low-shelve filter (-5dB – +3dB) | < 300Hz |
| Level-fix dip switch | ○ |
| Filter-fix dip switch | ○ |
| Connectors | |
| XLR in (impedance) | ○ (10k) |
| RCA in (impedance) | ○ (10k) |
| Power consumption | |
| Standby | < 1W |
| Full output | 70VA |
| Misc. | |
| Backmounting thread inserts | ○ |
| Mic stand thread inserts | ○ |
| Weight kg/lb. | 5 / 11 |
