Spec
- Power Output (RMS)
- 427W
- Frequency Response
- -3dB at 35Hz and 14kHz
- Speaker Outputs
- speakon/Jack
- High Instrument Input
- impedance 1m Ohms,input range 25mV - 1.5V p-p
- Low Instrument Input
- impedance 100k Ohms,input range 25mV - 6V p-p
- Line Input
- impedance 100k Ohms,input level 0dBu nominal
- DI Output
- 600 Ohms balanced,level 0dBu nominal
- Impedance
- 2 Ohms
- EQ
- -3dB at 35Hz and 14kHz
- Effects Send
- 1k Ohms,level 0dBu nominal
- Effects Return
- 1M Ohms,input level 0dBu Nominal
- Pre-Amp Tubes
- 1 x ECC83 1 x ECC82
- Output Tubes
- 8 x KT88's
- H x W x D (mm)
- 362 x 610 x 300
- Weight (kg)
- 35
