Spec
- Transducer type
- Capacitive pressure transducer
- Frequency range
- 10 Hz to 8 kHz (± 1 dB)
- Open-circuit Sensitivity
- 50 mV/Pa
- Open-circuit Sensitivity re 1 V/Pa
- -26 dB ±1,5 dB re 1V/Pa
- Max. SPL for 3% THD at 1 kHz
- 146 dB
- Inherent noise with preamplifier MV 203
- 11 dBA
- Resonance frequency
- 8,5 kHz
- Polarization voltage
- 200 V
- Capacitance at 1 kHz
- 64 pF
- Operating temperature range
- - 50 °C to +100 °C
- Main ambient temperature coefficient
- ≤ 0,01 dB/K
- Main ambient pressure coefficient
- -1 x 10-5dB/Pa
- Diameter
- 23,77 mm ± 0,02 mm
- Height
- 26,5 mm
- Weight
- 55 g
- Preamplifier thread
- 23,11 mm60 UNS
- Protection grid thread
- M 23 x 0.35
