特徴
・ 16 Hzまでのモニタリングシステムの低域拡張
・ システム全体の最大SPLを向上
・ スピーカーの高調波歪みおよび相互変調歪みの低減
・ MA 1 に対応しており、システム全体の完璧な調整とシームレスなサブウーファー統合が可能です。マルチチャンネル構成には、MA 1 Multichannel Extensionオプションをご用意しております。
・ アナログKHスピーカーへのMA 1の統合により、ステレオシステム全体に十分なDSPパワーを提供。
・ システム全体の最大SPLを向上
・ スピーカーの高調波歪みおよび相互変調歪みの低減
・ MA 1 に対応しており、システム全体の完璧な調整とシームレスなサブウーファー統合が可能です。マルチチャンネル構成には、MA 1 Multichannel Extensionオプションをご用意しております。
・ アナログKHスピーカーへのMA 1の統合により、ステレオシステム全体に十分なDSPパワーを提供。
Spec
| Acoustics | |
|---|---|
| Free field frequency response ±6 dB | 16 ... 750 Hz |
| Free field frequency response ±3 dB | 18 ... 310 Hz |
| Frequency response ripple; range, deviation | 20 ... 295 Hz, ±1.5 dB |
| Self-generated noise at 10 cm (with input gain set to 100 dB SPL for 0 dBu) | <20 dB(A) SPL |
| Sine wave output with a THD < 0.5 % at 1 m in half space | 95 dB SPL (42 - 200 Hz) |
| Bass capability: Max. SPL in half space at 3% THD at 1m (averaged between 50 Hz and 100 Hz) | 110 dB |
| Max. SPL for subwoofers: on floor; against the wall; in the corner | 110 dB; 113 dB; 116 dB; |
| Dolby DARDT. Max SPL bass managed | 118 dB SPL |
| Acoustical Principle | Bassreflex, Ports at the front |
| Analog Inputs and Outputs | |
| Analog input(s) | 2 x XLR: electronically balanced; |
| Analog input impedance | >13k Ohms |
| Max. input level for 100 dB SPL Output Level and 0 dB Gain Setting | +24 dBu |
| Max. input level | 24 dBu |
| Common mode rejection ratio (CMRR), XLR / Sub-D | > 56 dB @ 15 kHz |
| Crosstalk (1 kHz), level matching, XLR / Sub-D | -90 dB; ±0.1 dB |
| Remote volume control | via MA 1 software |
| Volume control range; resolution | 0 … -∞ dB; 0.1 dB |
| Analog dynamic range; THD+N (A-D-A), XLR / SubD | 119 dB(A); <0.003% (-90 dB) |
| Signal routing modes | Right; External Bass Management; 2 x LFE |
| Analog output(s) | 2 x XLR; analog electronically balanced |
| Digital Inputs and Outputs | |
| Digital input(s) | BNC (75 Ω): AES3; S/P-DIF |
| Digital output(s) | BNC (75 Ω): AES3 |
| Digital converter: resolution; design | 16 … 24-bit DAC; Δ∑ |
| Digital converter: sampling rate | 22.05; 24; 32; 44.1; 48; 64; 88.2; 96; 176.4; 192 kHz |
| Digital internal sampling rate | 48 kHz |
| Output sampling rate | 48 kHz |
| Dynamic range A-D-A (Converter) | >120 dB(A) |
| Dynamic range D-A | >123 dB(A) |
| Digital sensitivity | -18 dBFS = 100 dB SPL at 1 m |
| Latency ADA / DA | 1.5 ms (A-D-A); 1.2 ms (D-A) |
| Delay: User adjustable delay range | 0 ... 100 ms and 2 x 0 ... 20.8 ms |
| Delay: Resolution: time; distance | 20.8 µs; 0.71 mm (0.28 ") |
| Delay: Max. frames Audio-video synchronisation (lip sync) | 2.5 (40 ms) frames; 3 (33 ms) frames |
| Delay: Time-of-flight maximum distance | 2 x 7.16 m (23' 5") |
| User Interface | |
| Status Indication | 2x Status LED on Backplate |
| Input gain control (sensitivity) | +2 ... -12 dB |
| Output level control (output level in 1 m based on 0 dBu input level) | 94; 100; 108; 114 dB SPL |
| Input Select | automatic; AES3id prio over analog |
| Ground Lift | Yes |
| Control | Local; Network |
| Equalization: Low cut | 30 Hz; 0 … -12 dB |
| Phase | 0; 45; 90; 135 and 0/180 deg |
| Mains Switch | Yes |
| Mains Voltage | Universal Power Supply 100 V~ … 240 V~ |
| Bass Management On | Yes |
| Electronics - Controller | |
| Controller design | Digital; active |
| Crossover frequency | 80 Hz fixed |
| Crossover slope | 24 dB/oct; 4th order |
| Supports automatic room calibration via MA 1 | Yes; Subwoofer and connected analog loudspeakers |
| FIR phase linearization | for connected analog loudspeakers in combination with MA 1 |
| Protection circuitry | peak limiter Amplifier, thermo limiter woofer, temperature limiter electronics, temperature limiter power supply, temperature limiter power amplifier, temperature protection amplifier, over current protection amplifier, over current protection power supply |
| Remote control | via Ethernet and MA 1 |
| Display: On; Normal Operation | Green LED on backplate |
| Display: Identification | Flashing red LED on backplate |
| Display: Limit / Clip / Errors / Protection /Boot Mute / Shut Down Mute | Red LED on backplate |
| Electronics - Amplifiers and Power Supply | |
| Output power woofer amplifier(THD+N with limiter deactivated: 10%) | 222 W |
| Output power woofer amplifier(THD+N with limiter activated: 10%) | 222 W |
| Mains Power Supply: input voltage; frequency | SMPS: 100-240 V; 50/60 Hz |
| Power consumption (230 V / 100 V): Standby | <300 mW |
| Power consumption (230 V / 100 V): Idle | 17 W |
| Power consumption (100 V): Full output | 310 W |
| Power consumption (230 V / 100 V): Full output | 310 W |
| Power consumption (240 V): Full output | 285 W |
| Standby | automatic, 20 mins (default) |
| Mechanics | |
| Cabinet material | Wood cabinet, aluminum electronics panel |
| Cabinet surface finish; color (front / back) | Painted; metallic anthracite (RAL 7021) / black(RAL 9005) |
| Operating conditions | +10° C to +40° C (+50° F to +104° F); <75% RH, non-condensing |
| Transport/storage conditions | -25° C to +60° C (-13° F to 140° F); <90% RH; non-condensing |
| Woofer | 265 mm (10") with protecting black metal grille |
| Product dimensions (height x width x depth) | 368 x 330 x 645 mm (14.5" x 13" x 25.4") |
| External net volume | 78 liters |
| Product weight | 25.5 kg (56 lbs 3 oz) |
| Packed dimensions (height x width x depth), mm (inches) | 484 x 454 x 749 (19.1" x 17.9" x 29.5") |
| Packed weight | 31.3 |
| Packaging weight inc. Cables and manuals | 5.8 |
| Packed cube | 0.165 m³ |
| Delivery includes | 1 x KH 805 II Mains cables: EU/KC; UK; US; China 1 x Getting Started Quickly guide 1 x Operating Manual |
| Acoustical Axis horizontal | 165 mm |
| Acoustical Axis vertical (from bottom) | 183.5 mm |
