Spec
- Frequency Range (-10 dB)
- 42 - 20000kHz
- Weatherized
- No
- Flying
- Yes
- Minimum Impedance
- 6.5Ω
- Nominal Impedance (Passive)
- 8Ω
- HF Transducer
- 1.25-inch DH3/2010A
- Speaker Type
- Full-Range, Mid-High, Two-Way, Wedges
- Woofer Size
- 15inch
- Powered or Passive
- Passive
- Frequency Response (-3 dB)1
- 60 ... 20000Hz
- Max. SPL/1m (calc)²
- 132dB
- Coverage (Nominal -6 dB) H
- 90°
- LF Transducer
- 15-inch EVS15-SF
- Coverage (Nominal -6 dB) V
- 50°
- Power Rating
- 1600W
- System Power Handling (Continuous/Program/Peak)
- 400//1600Watts
- Crossover Frequency
- 1500Hz
- Enclosure Material
- High Impact Polystyrene Composite
- Grille
- Polyester Powder Coated, 18GA Galvanized Steel
- Available Color
- Black
- Sensitivity 1 W/1 m
- 100dB
- Height
- 686mm
- Width
- 445mm
- Recommended High-Pass Frequency
- 42Hz
- Depth
- 406mm
- Weight Net
- 20.2kg
- Family
- ZxZxA
- Input Connections
- Parallel Neutrik® NL4
- Chassis Size
- 381mm
