Spec
| ADC | Sigma - Delta Cnverter 24 Bit 96kHz in two volume levels | |
| Current consumption | < 100 mA | |
| Power supply | 5,6 V to 15V | |
| Polarization voltage | 200 V | |
| Frequency range | 1 Hz to 40 kHz | |
| Dynamic range | > 140 db in two separate volume levels | |
| Sample rate | 96 kHz / 48 kHz | |
| Input impedance | 20 GOhm0,2 pF | |
| Inherent noise | A-weighted | ≤ 2,5 μVeff |
| with microphone capsule MK 221 | 15 dB - A | |
| Maximum input | Channel 1 | 24 V |
| Channel 2 | 0,24 V | |
| Volume levels | Channel 1 | with MK 221(50 mV/Pa) 146dB |
| Channel 2 | 106 dB | |
| Remote control | High pass | 10 Hz |
| Sample rate | 96 kHz / 48 kHz | |
| Polarization | positiv / negativ | |
| Connection to | 1. AES 42 - 2001 | 1. AES 42 - 2001 |
| 2. AES 3 - 1992 (AES/EBU) + Supply voltage + RC data | 2. AES 3 - 1992 (AES/EBU) + Supply voltage + Control remote data | |
| 3. SPDIF | 3. SPDIF (on request) | |
| Plug | XLR 5 M | |
| Capsule thread | 11,7 mm 60 UNS | |
| Diameter | 直径 12,7 mm / 21 mm | |
| Length | 158 mm | |
| Weight | 87 g | |
