Spec
| Load Impedance | 2 Ω | 2.6 Ω | 4 Ω | 8 Ω |
| Maximum Output Power, Single Channel | 1600 W | 1300 W | 950 W | 480 W |
| Maximum Output Power, Dual Channel | 1400 W | 1200 W | 850 W | 450 W |
| Maximum Output Power, Bridged | - | - | 2800 W | 1700 W |
| Direct Drive Load Capability Dual Channel Bridged | 70 V Operation 2 x 1250 W (-1.5 dB) Not recommended1 | 100 V Operation Not available21 x 1250 W (-1.5 dB) | ||
- Maximum RMS Voltage Swing (THD = 1%, 1 kHz)
- 65.1 V
- Voltage Gain (Ref. 1 kHz)
- 32.0 dB
- THD at 600 W/4 Ω (MBW = 80 kHz, 1kHz)
- < 0.05%
- IMD-SMPTE (60 Hz, 7 kHz)
- < 0.1%
- DIM30 (3.15 kHz, 15 kHz)
- < 0.05%
- Maximum Input Level
- +21 dBu
- Crosstalk (Ref. 1 kHz, at 100W/4 Ω)
- < -80 dB
- Frequency Response (Ref. 1 kHz)
- 20 k Ω
- Signal to Noise Ratio (Amplifier, A-weighted, Ref to Max. Output Power @ 8 Ω)
- >105 dB
- Output Noise (A-weighted)
- < -68 dBu
- Output Stage Topology
- Class AB
- Power Requirements
- 240 V, 230 V, 120 V, or 100 V; 50 Hz to 60 Hz (factory configured)
- Power Consumption (⅛ Maximum Output Power @ 4 Ω)
- 700 W
- Mains Fuse
- 240 V/230 V: T12AH; 120 V/100 V: T25AH
- Protection
- Audio limiters, high temperature, DC, HF, Back-EMF, Peak current limiters, Inrush current limiters, Turn on delay
- Cooling
- Front-to-rear, 3-stage-fans
- Ambient Temperature Limits
- +5°C to +40°C (40°F to +105°F)
- Safety Class
- I
- Color
- Black
- Dimensions (W x H x D), mm
- 483 x 88 x 462.4
- Weight
- 15.2 kg (33.5 lb)
- Remote Power ON/GPIO
- Power remote via switch, delay time selectable. Floating relay contacts (show protect mode). Inputs for preset selection.
- Signal Processing
- FIR filters, audio limiters, output and array** delay, 10-band** user PEQ, 5-band array PEQ** per channel, load impedance
- Remote Control
- SONICUE sound system software **
- Accessories
- RMK15 (rear rack mount kit)
