本体Spec
| Frequency Response (-3dB) | 77 Hz–20 kHz | Power Handling | 350 W cont. / 700 W prog. / 1400 W peak |
| Frequency Range (-10dB) | 65 Hz–20 kHz | Enclosure Tuning | 60 Hz |
| Sensitivity 1 W/1 m | 99 dB | Crossover Frequency | 2000 Hz |
| Max SPL/ 1m (calc) | 130 dB | Nominal Impedance | 8 Ω |
| Coverage (HxV) | 55° x 80° | Minimum Impedance | 5.1 Ω |
| Connectors (standard/E) | Parallel ¼" phone / Parallel Speakon NL4MP | Transducer Complement (HF/LF) | DH2010A, HP85M constant directivity / DL15BFH |
| Enclosure Material | RoadWood w/ black carpet finish | Max. Woofer Acoustic Output | 8.3 Watts |
| Dimensions (HxWxD) | 40.6 x 64.5 x 47.1 cm (16.0" x 25.4" x 18.5") | Weight | 19.5 kg (43 lbs) |
