Spec
◎TUBES
Preamp:8 x 12AX7A
Power amp:1 x 12AX7A, 4 x EL34
◎INPUTS
Instrument:-26 dB/1 MΩ
Power Amp In:+2 dB (AMP 1B + AMP 3)/1 MΩ, +9 dB (AMP 1A + AMP 2)/1 MΩ
FX -Return:-10 dB or -20 dB/48 kΩ
◎OUTPUTS
Preamp Out:+6 dB/47Ω
FX - Send:+9 dB or +19 dB/2,2 kΩ
◎Red Box
DI out: -26 to -10 dB/220Ω
OUTPUT POWER100 watts into 4, 8, 16Ω
◎GENERAL
VOLTAGE:100 volts AC (Japanese version)
MAINS FUSE:2 x T4A (100V version)
ANODE FUSE:1 x T500mA
INTERNAL FUSES:2 x T630 mA ・ 1 x TT15 A
MAX. POWER CONSUMPTION:506 VA
AMBIENT TEMPERATURE RANGE:-10 °C to +35 °C
DIMENSIONS (W x D x H):748 x 256 x 330 mm
WEIGHTS:22 kg
Preamp:8 x 12AX7A
Power amp:1 x 12AX7A, 4 x EL34
◎INPUTS
Instrument:-26 dB/1 MΩ
Power Amp In:+2 dB (AMP 1B + AMP 3)/1 MΩ, +9 dB (AMP 1A + AMP 2)/1 MΩ
FX -Return:-10 dB or -20 dB/48 kΩ
◎OUTPUTS
Preamp Out:+6 dB/47Ω
FX - Send:+9 dB or +19 dB/2,2 kΩ
◎Red Box
DI out: -26 to -10 dB/220Ω
OUTPUT POWER100 watts into 4, 8, 16Ω
◎GENERAL
VOLTAGE:100 volts AC (Japanese version)
MAINS FUSE:2 x T4A (100V version)
ANODE FUSE:1 x T500mA
INTERNAL FUSES:2 x T630 mA ・ 1 x TT15 A
MAX. POWER CONSUMPTION:506 VA
AMBIENT TEMPERATURE RANGE:-10 °C to +35 °C
DIMENSIONS (W x D x H):748 x 256 x 330 mm
WEIGHTS:22 kg
