スペック
Bypass method: Relay True Bypass or Analog Buffered.
Buffer Specifications:
Type: Discrete Class A, JFET input
Input Impedance: Input Buffer: 1 MΩ
Max. Input Level: +12 dBu
Frequency Response: +0.0/-0.2 dB, 10 Hz - 100 kHz
S/N Ratio: >96 dB, 0 dBV ref. (no weighting)
THD+N: <0.004%, -10 dBV, 20 Hz - 30 kHz
Output impedance: 400 Ω
Max. Output Level: +12 dBu into 10 kΩ
Power: 9-12 VDC, 200 mA, center negative
(12V DC isolated & regulated recommended)
Dimensions: 13.2" x 5" x 1.6" (W x D x H)
Weight: 3 lbs.
Buffer Specifications:
Type: Discrete Class A, JFET input
Input Impedance: Input Buffer: 1 MΩ
Max. Input Level: +12 dBu
Frequency Response: +0.0/-0.2 dB, 10 Hz - 100 kHz
S/N Ratio: >96 dB, 0 dBV ref. (no weighting)
THD+N: <0.004%, -10 dBV, 20 Hz - 30 kHz
Output impedance: 400 Ω
Max. Output Level: +12 dBu into 10 kΩ
Power: 9-12 VDC, 200 mA, center negative
(12V DC isolated & regulated recommended)
Dimensions: 13.2" x 5" x 1.6" (W x D x H)
Weight: 3 lbs.
