Spec
Input Impedance : 1MΩ
Output Impedance : 1kΩ
Max Input Level : +5 dBV, 500 Hz
Max Output Level : +8 dBV
Noise Floor**
Mix at Max CW : -96 dBV
Mix at Max CCW : -104 dBV
Delay Distortion : <1%, 1 kHz -5 dBV Input
Delay Time : 20 ms to 600 ms
Noise Reduction : 2:1 ratio
Modulation Speed : 0.2 Hz to 2.2 Hz
Bypass : True Hardwire
Current Draw : 26 mA
Power Supply : 9 volts DC
Output Impedance : 1kΩ
Max Input Level : +5 dBV, 500 Hz
Max Output Level : +8 dBV
Noise Floor**
Mix at Max CW : -96 dBV
Mix at Max CCW : -104 dBV
Delay Distortion : <1%, 1 kHz -5 dBV Input
Delay Time : 20 ms to 600 ms
Noise Reduction : 2:1 ratio
Modulation Speed : 0.2 Hz to 2.2 Hz
Bypass : True Hardwire
Current Draw : 26 mA
Power Supply : 9 volts DC
