Spec
Input Impedance / Buffer Switch On : 800 kΩ
Output Impedance / Buffer Switch Off : 10 kΩ
Output Impedance @ 1 KHz, Maximum Volume : ～16 K ohm
Output Impedance @ 1 KHz, -6dB Volume : ～120 K ohm
Maximum Output Leve : -4 dBV
Maximum Gain @ 1 KHz, Volume & Fuzz Max : 55 dB typ
Bypass : True Hardwire Bypass
Power Requirements : 2.5 ma @ 9VDC
Output Impedance / Buffer Switch Off : 10 kΩ
Output Impedance @ 1 KHz, Maximum Volume : ～16 K ohm
Output Impedance @ 1 KHz, -6dB Volume : ～120 K ohm
Maximum Output Leve : -4 dBV
Maximum Gain @ 1 KHz, Volume & Fuzz Max : 55 dB typ
Bypass : True Hardwire Bypass
Power Requirements : 2.5 ma @ 9VDC
