SPEC
FRONT PANEL INPUT
Connector :1/4" phone jack, unbalanced.
Inpedance :1 MegaOhm (less if Input Impedance is active)
Max. Input Level :+16 dBu (conditioned for guitar use)
REAR INPUTS
Connector :1/4" phone jack, balanced.
Inpedance :1 MegaOhm
Max. Input Level :+20 dBu
A/D CONVERSION
Bit Depth :24 bits
Sample Rate :48 kHz
Dynamic Range :> 110 dB
Frequency Response :20 - 20kHz, +0 / -1 dB
Crosstalk :> -60 dB over full bandwidth
ANALOG OUTPUTS
Connectors :1/4" phone jack unbalanced XLR balanced (for main output)
Impedance :600 ohm
Max Output Level :+20 dBu
Dynamic Range :> 110 dB
Frequency Response :20 - 20kHz, +0 / -1 dB
Crosstalk:< -60 dB over full bandwidth
DIGITAL I/O
Connectors:RCA Coaxial Type for S/PDIF I/O, XLR for AES I/O
Format :S/PDIF - 24 bit
Sample Rate :48 kHz
MIDI INTERFACE
Input Connector :7-pin DIN (pins 6 & 7 to phantom power in jack)
Out/Thru Connector :5-pin DIN PEDAL INTERFACE
Connector :1/4" TRS phone jack
Format :Switch: Momentary or Latching; Pedal: 10 - 100kΩ max, linear taper expression type.
MFC INTERFACE
Connector :RJ-45 "CAT5"(コンピューターやルーターには接続出来ません。)
GENERAL
Dimensions :483 × 88 × 362 mm)
Weight :10 lbs. (4.5 kg)
Input Voltage :100 - 240 VAC, 47 - 63 Hz (universal input)
Power Consumption :< 40 W
Backup Battery Life :> 10 years
Backup Battery Type :CR2450 Lithium
