Spec
- Basic features
 - Q factor
 - Variable (Proportional), 0.3 - 6
 - Hard wire bypass
 - No. The signal still goes by transformers and tubes
 - Boost/Cut Range
 - +/-6dB or +/-12dB, specified by orders
 - All stepped manipulators
 - 24 pole Elma switches

- Input & Output
 - Interstage transformers
 - Yes, UTM3525, gapped
 - Input Impedance (balanced)
 - XLR, 10k Ohm, UTM2546
 - Output Impedance (balanced)
 - XLR, 600 Ohm, UTM3525
 - Audio transformers
 - Input & Output: UTM transformers

- Levels
 - Operating Level
 - +4 dBu
 - Max output level
 - +26 dBu
 - Max output level
 - +22 dBu
 - Dynamic Range
 - >112 dB (@ 1kHz, +24 dBu)
 - Max. gain
 - 0dB; +/-12dB each band

- Bandwidth
 - Frequency response
 - 10Hz - 50kHz (+/-0.4 dB)

- Distortion (@ 20 Hz - 20 kHz)
 - Signal to Noise Ratio
 - 102dB @ +24dBu, 1kHz
 - THD+N
 - <0.049% @ +24dBu, 1kHz
 - Crosstalk
 - 96 dB @+4dBu, 1kHz

- Power
 - Voltage
 - 115/230V, 60/50Hz
 - Power consumption
 - 45W
 - Power supply
 - internal, linear

- Packing box
 - Dimensions
 - 70x40x30 cm
 - Shipping weight
 - 12 kg

- Others
 - Tube set
 - 6xECC88 or 6xE88CC or 6x6N23P or 6x6N1P-EV
