Spec
- Power Output (RMS)
- 575W
- Speaker Configuration
- 2 x 10" bass drivers + HF tweeter
- Frequency Response
- -3dB at 17Hz and 30kHz
- Speaker Outputs
- 2 x Jack/Speakon Outputs
- High Instrument Input
- Impedance 3.9m Ohms,input range 150mV - 20mV p-p
- Low Instrument Input
- Impedance 10k Ohms,input range 300mV - 40V p-p
- Line Input
- Impedance 22k Ohms,input level 0dBu nominal
- Sub Output
- Impedance 1k Ohms,level 0dBu Nominal
- DI Output
- 600 Ohms balanced,level 0dBu nominal
- Tuner Output
- Impedance 22k Ohms,level 0dBu nominal
- Impedance
- 8 ohm
- Output Impedance
- Minimum 4 ohm
- Effects Send
- Impedance 22k Ohms,level 0dBu nominal
- Effects Return
- Impedance 22k Ohms,input level 0dBu Nominal
- Pre-Amp Tubes
- 1 x 12AX7
- H x W x D (mm)
- 587 x 610 x 335
- Weight (kg)
- 30
