Spec
| INPUT: | Input Impedance | 2 M-ohms // 33pF | |
| GAIN: | Gain Range | min / max | -∞ / +30dB |
| Gain Peak LED | +10 dBv | ||
| Frequency Response | +0 / -3dB | 20 – 20.000 Hz | |
| BOOST: | HI: | Type | Shelving High Pass |
| Gain | +3dB @ 10kHz | ||
| LO: | Type | Shelving Low Pass | |
| Gain | +7dB @ 40Hz | ||
| COMP / LIMIT: | Compressor Gain | 0dB | |
| Attenuation | max | 24dB | |
| Conpression Ratio | max | 3:1 | |
| Attack (80%) | typ. | < 10 ms | |
| Release (80%) | typ. | 100 ms | |
| FILTER SECTION: | Bass Filter: | Type | 12dB / oct. Shelving |
| Frequency Setting | 60 / 80 / 100 Hz | ||
| Gain Range | + / – 16 | ||
| Lo Mid Filter: | Type | Bandpass Filter | |
| Frequency Range | 95 – 3,000 Hz | ||
| Q | 0.8 | ||
| Gain Range | + / – 16 | ||
| Hi Mid Filter: | Type | Bandpass Filter | |
| Frequency Range | 200 – 7,000 Hz | ||
| Q | 0.8 | ||
| Gain Range | + / – 16 | ||
| Treble Filter: | Type | Shelving | |
| Gain Range | + / – 16 | ||
| Frequency Setting | 5.5 / 8.0 kHz | ||
| Bright: | Type | Shelving | |
| Gain Range | +24 / -0 dB @ 10kHz | ||
| DRIVE SECTION: | Gain Range | min / max | 0 / 34 dB |
| Low End Compression | < 350 Hz | ||
| BALANCED OUTPUT: | Output Level | nominal | -10dBv |
| Frequency Responce | +0 / -3 dB | 10 – 20.000 Hz | |
| XLR Connectors | 1-GND, 2-Hot, 3-Cold | ||
| Options | GND lift, Pre and Post EQ, Spkr sim(Post EQ) | ||
| EFFECT LOOP: | Loop Signal Level | nominal | -10dBv |
| Gain | Unity (1:1) | ||
| Output Impedance | < 100ohms | ||
| input Impedance | 100k ohms // 100pF | ||
| LINE OUT: | Output Impedance | 2k ohms | |
| Signal Level | nominal | 0 dBv | |
| TUNER OUT: | Output Impedance | 250 ohms | |
| Signal Level | as input | ||
| POWER AMP: | Output Power | @ 4 ohms | 450W RMS |
| @ 2 ohms | 750W RMS | ||
| Minimum Load Impedance | 2 ohms | ||
| Protection | DC, thermal and high frequency (HF) | ||
| AUXILIARY INFO: | Power Requirements | max 900W | |
| Mains Protection | T10A Fuse(100V) | ||
| imensions (W x D x H) | max | 48 x 36 x 13 (cm) : 3U | |
| Weight | net | 14.4 kg |
