spec
Nominal Input Level - 8 dBv
Input Impedance 700 kohms
Bandwidth +0/-3 dB 20 - 20 kHz
Delay Bandwith +0/-3 dB 200 - 8 kHz
Delay Level mix min/max -oo - +3 dB
Center Delay Time Flange 3 ms
Chorus 5.5 ms
Pitch Modul. 10 ms
Modulation Depth min/max +/- 50% of nominal delay time
LFO Range min/max 0.15 - 7.5 Hz
Bypass True Bypass
Dimensions (L x W x H) 2.8 x 4.5 x 1.4"
(70 x 115 x 35 mm)
Weight 400g (0.88 lb.)
Power Requirements 9V - 12V DC Regulated, 35 mA max
Input Impedance 700 kohms
Bandwidth +0/-3 dB 20 - 20 kHz
Delay Bandwith +0/-3 dB 200 - 8 kHz
Delay Level mix min/max -oo - +3 dB
Center Delay Time Flange 3 ms
Chorus 5.5 ms
Pitch Modul. 10 ms
Modulation Depth min/max +/- 50% of nominal delay time
LFO Range min/max 0.15 - 7.5 Hz
Bypass True Bypass
Dimensions (L x W x H) 2.8 x 4.5 x 1.4"
(70 x 115 x 35 mm)
Weight 400g (0.88 lb.)
Power Requirements 9V - 12V DC Regulated, 35 mA max
