Spec
- Type
- Condenser
- Frequency Response
- 20 to 20,000 Hz
- Polar Pattern
- Cardioid
- Sensitivity (at 1,000 Hz)
- Open circuit voltage: -45 dBV/Pascal (5.6 mV) (1 Pa = 94 dB SPL)
- Impedance
- Rated at 150 &Omega (85 &Omega actual)
Recommended minimum load impedance: 800 &Omega - Output Clipping Level
- 800 &Omega Load: -4 dBV (0.63 V)
150 &Omega Load: -15 dBV (0.18 V) - Maximum SPL (at 1,000 Hz)
- 800 &Omega load: 136 dB (attenuator at 0) 146 dB (attenuator at -10)
150 &Omega load: 128 dB (attenuator at 0) 138 dB (attenuator at -10) - Self-Noise
- 16 dB typical, A-weighted
19 dB typical, weighted per DIN 45 405 - Hum Pickup
- -3 dB equivalent SPL in a 1 mOe field (60 Hz)
- Signal-to-Noise Ratio
- 78 dB (IEC 651)* at 94 dB SPL
S/N ratio is difference between 94 dB SPL and equivalent SPL of self- noise A-weighted - Overvoltage and Reverse Polarity Protection
- Max. external voltage applied to pins 2 and 3 with respect to pin 1: +52 Vdc
Reverse polarity protection: 200 mA max. (diode-clamped) - Polarity
- Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3
- Power
- 11 to 52 vdc, 1.2 mA
- Case
- Steel construction with vinyl metallic paint finish and stainless steel screens
- Connector
- Three-pin professional audio connector (male XLR type)
- Weight
- 230 g
- Dimensions
- 212 mm L x 23.5 mm W
