Spec
■CHANNELS : 3
■IN CH1 (1/4" jack) and IN CH2 (1/4" jack) : Impedance 1MΩ, max. voltage 5 Vpp
■IN CH3 (combo jack) UNBALANCED BALANCED : Impedance 22KΩ, max. voltage 5 Vpp | Impedance 2KΩ, max. voltage 6 Vpp
■other INPUTS : LINK 1 (1/4″ jack) and LINK 2 (1/4″ jack)
■PHANTOM POWER (48V) : on CHANNEL 3 (with on/off switch)
■CONTROLS (each channel) : GAIN | VOLUME | HIFIZER | OLD SCHOOL
■OUTPUT SELECTOR : switch OUT 1 / OUT 2 (on each channel)
■OUTPUTS : BALANCED OUT 1 (with GND) and BALANCED OUT 2 (with GND), OUT 1 (1/4″ jack) and OUT 2 (1/4″ jack)
■POWER REQUIREMENT : 9 to 12VDC | 120mA (power supply included)
■DIMENSIONS (W/D/H) : 15.5cm x 12.7cm x 5.2cm
■WEIGHT : 830g
■IN CH1 (1/4" jack) and IN CH2 (1/4" jack) : Impedance 1MΩ, max. voltage 5 Vpp
■IN CH3 (combo jack) UNBALANCED BALANCED : Impedance 22KΩ, max. voltage 5 Vpp | Impedance 2KΩ, max. voltage 6 Vpp
■other INPUTS : LINK 1 (1/4″ jack) and LINK 2 (1/4″ jack)
■PHANTOM POWER (48V) : on CHANNEL 3 (with on/off switch)
■CONTROLS (each channel) : GAIN | VOLUME | HIFIZER | OLD SCHOOL
■OUTPUT SELECTOR : switch OUT 1 / OUT 2 (on each channel)
■OUTPUTS : BALANCED OUT 1 (with GND) and BALANCED OUT 2 (with GND), OUT 1 (1/4″ jack) and OUT 2 (1/4″ jack)
■POWER REQUIREMENT : 9 to 12VDC | 120mA (power supply included)
■DIMENSIONS (W/D/H) : 15.5cm x 12.7cm x 5.2cm
■WEIGHT : 830g
