Spec
出力(RMS): 1/4W~20W
出力(Peak): 25W@16Ω(Max)<外部16Ωスピーカー1台使用時> , 50W@8Ω(Max) <外部8Ωスピーカー1台使用時>プリ真空管: EF86 × 1, 12AX7 × 3
パワー真空管: EL84 × 2
整流管: 5AR4 (GZ34)
コントロール: Power Switch, Standby Switch, Power Control, Cut Control, [Top Boost Section] Bass Control, Treble Control, Volume Control, [Nomal Section] Volume Control, Bright Switch, Bass/Treble Switch Preamp Tube Selector Switch
対応電源: 100VAC, 50/60Hz
スピーカー出力端子: 16Ω x 1, 8Ω x 2
外形寸法: 7.5″ (D) x 17″ (W) x 9.75″ (H)
重量: 約11kg
出力(Peak): 25W@16Ω(Max)<外部16Ωスピーカー1台使用時> , 50W@8Ω(Max) <外部8Ωスピーカー1台使用時>プリ真空管: EF86 × 1, 12AX7 × 3
パワー真空管: EL84 × 2
整流管: 5AR4 (GZ34)
コントロール: Power Switch, Standby Switch, Power Control, Cut Control, [Top Boost Section] Bass Control, Treble Control, Volume Control, [Nomal Section] Volume Control, Bright Switch, Bass/Treble Switch Preamp Tube Selector Switch
対応電源: 100VAC, 50/60Hz
スピーカー出力端子: 16Ω x 1, 8Ω x 2
外形寸法: 7.5″ (D) x 17″ (W) x 9.75″ (H)
重量: 約11kg
