Spec
- Transducer type
- Dynamic
- Operating principle
- Pressure gradient
- Polar pattern
- Hypercardioid
- Frequency response
- 40 - 18,000 Hz
- Rear attenuation at 1 kHz
- > 20 dB at 120°
- Sensitivity (0 dB = 1 V/Pa)
- 1.2 mV/Pa (= -58 dBV)
- Magnetic field suppression
- > 18 dB at 50 Hz
- Nominal impedance
- 200 Ω
- Load impedance
- ≥ 1000 Ω
- Diaphragm
- Hostaphan®
- Case/finish
- Brass
- Connector
- XLR, 3-pin, male
- Dimensions: Length
- 147 mm
- Dimensions: Shaft diameter
- 24 mm
- Dimensions: Head diameter
- 24 mm
- Weight
- 228 g
