Spec
Conductor-Size | 0.75 ㎟ |
---|---|
Construction(No/mm) | 150/0.08 OFC |
Diameter | 0.14mm |
Inner Jacket Thicness | 1.43mm |
Inner Jacket Diameter | 4.0 mm |
Conductor Vinyl Thicness | 0.25mm |
Conductor Vinyl Dimater | 4.5 mm |
Braided Shield Construction | 6 x 16 / 0.12OFC |
Braided Shield Dimeter | 5.0 mm |
PVC Jacket Thicness | 0.76mm |
PVC Jacket Dimeter | 6.5 mm |
Maximum Conductor Resistance(20°C) | 23.8Ω/km |
Capacitance(1kHz)-Approx | 100pF/m |
