Spec
Input impedance: > 1MΩ
Output Impedance: ~100Ω
Ratio: 1:1 to inf:1
Threshold: -40dB to +10dB
Make-up gain: -6dB to +20dB
0dB input referrence level:FF = ‐26dBu (50mV), FB = ‐28dBu (40mV)
THD: 0.1%以下 1kHz, 0dBu in/out, 600Ω load, 24KHz BW, 12VDC power,through 6th harmonic
Max Input Level: +5.5dBu
Max Output Level: +5.5dBu
Output frequency response: -2dB @ 40Hz; 0dB @ 100Hz - 22KHz
Optimal Power Voltage: 9-12VDC ±10% Center Negative Barrel
DC Power Plug Barrel: 直径 5.1/2.1mm, 12mm long
Power Consumtion:38mAh以下
Product Size: Lenght: 39mm, Depth: 92mm, Height: 51mm
Product Weight: 165g
Output Impedance: ~100Ω
Ratio: 1:1 to inf:1
Threshold: -40dB to +10dB
Make-up gain: -6dB to +20dB
0dB input referrence level:FF = ‐26dBu (50mV), FB = ‐28dBu (40mV)
THD: 0.1%以下 1kHz, 0dBu in/out, 600Ω load, 24KHz BW, 12VDC power,through 6th harmonic
Max Input Level: +5.5dBu
Max Output Level: +5.5dBu
Output frequency response: -2dB @ 40Hz; 0dB @ 100Hz - 22KHz
Optimal Power Voltage: 9-12VDC ±10% Center Negative Barrel
DC Power Plug Barrel: 直径 5.1/2.1mm, 12mm long
Power Consumtion:38mAh以下
Product Size: Lenght: 39mm, Depth: 92mm, Height: 51mm
Product Weight: 165g
